Product Summary
The BZX84-C5V1 is low-power voltage regulator diode in small SOT23 plastic SMD packages. The BZX84-C5V6 is available in the normalized E24 ±1% (BZX84-A), ±2% (BZX84-B) and approx. ±5% (BZX84-C) tolerance range. The series consists of 37 types with nominal working voltages from 2.4 to 75 V.
Parametrics
BZX84-C5V1 absolute maximum ratings: (1)continuous forward current, IF: 200mA; (2)total power dissipation, Tamb = 25℃, Ptot: 250mW; (3)non-repetitive peak reverse power dissipation, PZSM: 40W; (4)storage temperature, Tstg: -65 to +150℃; (5)junction temperature, Tj: -65 to +150℃.
Features
BZX84-C5V1 features: (1)Total power dissipation: max. 250 mW; (2)Three tolerance series: ±1%, ±2% and approx. ±5%; (3)Working voltage range: nom. 2.4 to 75 V (E24 range); (4)Non-repetitive peak reverse power dissipation: max. 40 W.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BZX84-C5V1 /T3 |
NXP Semiconductors |
Zener Diodes DIODE ZENER 5 PCT TAPE-11 |
Data Sheet |
Negotiable |
|
||||||||||||
|
BZX84-C5V1,215 |
NXP Semiconductors |
Zener Diodes 250MW 5.1V 5% |
Data Sheet |
|
|
||||||||||||
|
BZX84-C5V1,235 |
NXP Semiconductors |
Zener Diodes DIODE ZENER 5 PCT |
Data Sheet |
|
|
||||||||||||
