Product Summary
The X9511WSIZT1 is a push button controlled potentiometer that is ideal for push button controlled resistance trimming. The X9511WSIZT1 is a resistor array composed of 31 resistive elements. Between each element and at either end are tap points accessible to the wiper element. The position of the wiper element is controlled by the PU and PD inputs. The position of the wiper can be automatically stored in E2 memory and then be recalled upon a subsequent power-on operation. The resolution of the X9511WSIZT1 is equal to the maximum resistance value divided by 31.
Parametrics
X9511WSIZT1 absolute maximum ratings: (1)Temperature under bias: -65℃ to +135℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on PU, PD, and VCC with respect to VSS: -1V to +7V; (4)Voltage on VH and VL referenced to VSS: -8V to +8V; (5)△V = |VH - VL|X9511W: 10V; (6)Lead temperature (soldering 10 seconds): 300℃; (7)Wiper current: ±1mA.
Features
X9511WSIZT1 features: (1)Push button controlled; (2)Low power CMOS: Active current, 3mA max; Standby current, 100μA max; (3)31 resistive elements: Temperature compensated; ±20% end to end resistance range; -5V to +5V range; (4)32 wiper tap points; (5)100 year wiper position data retention; (6)X9511W = 10KΩ; (7)Packages: 8 Ld PDIP; 8 Ld SOIC; (8)Pb-free plus anneal available (RoHS compliant).
Diagrams
