Product Summary
The MURS160 is a 1.0A surface mount super-fast rectifier.
Parametrics
MURS160 absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 600 V; (2)Working Peak Reverse Voltage: 600 V; (3)DC Blocking Voltage: 600 V; (4)RMS Reverse Voltage: 424 V; (5)Average Rectified Output Current @ TT = 150℃: 1.0 A, @ TT = 125℃: 2.0 A; (6)Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave Superimposed on Rated Load (JEDEC Method): 35 A; (7)Forward Voltage @ IF = 1.0A, TJ = 25℃: 1.25 V, @ IF = 1.0A, TJ = 150℃: 1.05 V; (8)Peak Reverse Current @ TA = 25℃: 5.0 μA; (9)at Rated DC Blocking Voltage @ TA = 150℃: 150 μA; (10)Operating and Storage Temperature Range: -65 to +175 ℃.
Features
MURS160 features: (1)Glass Passivated Die Construction; (2)Super-Fast Recovery Time For High Efficiency; (3)Low Forward Voltage Drop and High Current Capability; (4)Surge Overload Rating to 35A Peak; (5)Ideally Suited for Automated Assembly; (6)Plastic Material: UL Flammability Classification Rating 94V-0.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MURS160 |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||
MURS160/1T |
Vishay Semiconductors |
Rectifiers 600 Volt 1.0A 50ns 35 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
MURS160/2CT |
Vishay Semiconductors |
Rectifiers 600 Volt 1.0A 50ns 35 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
MURS160/2T |
Vishay Semiconductors |
Rectifiers 1.0 Amp 600V 25ns 35 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
MURS160/2BT |
Vishay Semiconductors |
Rectifiers 600 Volt 1.0A 50ns 35 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
MURS160/2 |
DIODE FAST 1A 600V SMB |
Data Sheet |
|
|
||||||||||||||
MURS160-13-F |
Diodes Inc. |
Rectifiers 600V 1A |
Data Sheet |
|
|
|||||||||||||
MURS160-E3/2CT |
Vishay Semiconductors |
Rectifiers 600 Volt 1.0A 50ns 35 Amp IFSM |
Data Sheet |
Negotiable |
|
