Product Summary
The BUZ71A is a N - Channel STripFET power MOSFET. It is widely used in high current, high speed switching solenoid and relay drivers, regulators.
Parametrics
BUZ71A absolute maximum ratings: (1)Drain-source Voltage (VGS=0), VDS: 50V; (2)Drain- gate Voltage (RGS=20kW), VDGR: 50V; (3)Gate-source Voltage, VGS: ±20V; (4)Drain Current (continuous) at Tc=25℃, ID: 13A; (5)Drain Current (pulsed), IDM: 52A; (6)Total Dissipation at Tc = 25℃, Ptot: 40W; (7)Storage Temperature, Tstg: -65 to 175℃; (8)Max. Operating Junction Temperature, Tj: 175℃.
Features
BUZ71A features: (1)13A, 50V; (2)rDS(ON) = 0.120; (3)SOA is Power Dissipation Limited; (4)Nanosecond Switching Speeds; (5)Linear Transfer Characteristics; (6)High Input Impedance; (7)Majority Carrier Device; (8)Related Literature; (9)TB334 Guidelines for Soldering Surface Mount Components to PC Boards.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 BUZ71A_R4941 |
Fairchild Semiconductor |
MOSFET TO-220AB N-Ch Power |
Data Sheet |
Negotiable |
|
||||
 |
BUZ71AL |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
BUZ71A |
STMicroelectronics |
MOSFET TO-220 N-CH 50V 30A |
Data Sheet |
Negotiable |
|
||||
