STP7NK80ZFP

N-channel 800 V, TO220F, 5.2A, Zener-protected SuperMESH Power MOSFET, low intrinsic capacitances

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~1.85 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~1.85

PartNumber:: STP7NK80ZFP

Brand:: STMicroelectronics - ST | Pack: TO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. James Blunt's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-31

From Other Seller

Part Number:STP7NK80ZFP
US $0.10 - 1.85
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The STP7NK80ZFP is a Zener-protected SuperMESH Power MOSFET. The STP7NK80ZFP is obtained through an extreme optimization of ST’s well established strip-based PowerMESH layout. In addition to pushing on-resistance significantly down, special care is taken to ensure a very good dv/dt capability for the most demanding applications.

Parametrics

STP7NK80ZFP absolute maximum ratings: (1)Drain-source voltage (VGS = 0):800V; (2)Gate- source voltage:±30V; (3)Drain current (continuous) at TC = 25℃:5.0A; (4)Drain current (continuous) at TC = 100℃:3.3A; (5)Drain current (pulsed):20.8A; (6)Total dissipation at TC = 25℃:30W; (7)Derating factor:0.24W/℃; (8)Gate source ESD:4000V; (9)Peak diode recovery voltage slope:4.5V/ns ; (10)Insulation withstand voltage (RMS) from all three leads to external heat sink:2500V; (11)Max operating junction temperature:-55℃ to 150℃; (12)Storage temperature:-55℃ to 150℃.

Features

STP7NK80ZFP features: (1)Extremely high dv/dt capability; (2)100% avalanche tested; (3)Gate charge minimized; (4)Very low intrinsic capacitances ; (5)Very good manufacturing repeatability.
