Product Summary
The BCV64B is a PNP general purpose double transistor. It is used in General purpose switching and amplification; For use in Schmitt-trigger applications.
Parametrics
BCV64B absolute maximum ratings: (1)VCBO collector-base voltage TR1: -30 V; TR2: -6 V; (2)VCEO collector-emitter voltage TR1: -30 V; TR2: -6 V; (3)VEBO emitter-base voltage: -6 V; (4)IC collector current (DC): -100 mA; (5)ICM peak collector current: -200 mA; (6)IB base current (DC): -100 mA; (7)Ptot total power dissipation: 250 mW; (8)Tstg storage temperature: -65 to +150 ℃; (9)Tj junction temperature: 150 ℃; (10)Tamb operating ambient temperature: -65 to +150 ℃.
Features
BCV64B features: (1)Low current (max. 100 mA); (2)Low voltage (max. 30 and 6 V).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BCV64B T/R |
NXP Semiconductors |
Transistors Bipolar (BJT) TRANS GP TAPE-7 |
Data Sheet |
Negotiable |
|
||||||||||||
|
BCV64B,215 |
NXP Semiconductors |
Transistors Bipolar (BJT) TRANS GP TAPE-7 |
Data Sheet |
|
|
||||||||||||
 |
BCV64B |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
