Product Summary
The X9318WS8IZT1 is a digitally controlled potentiometer (XDCP). The device consists of a resistor array, wiper switches, a control section, and nonvolatile memory. The wiper position is controlled by a 3-wire interface. The potentiometer is implemented by a resistor array composed of 99 resistive elements and a wiper switching network.
Parametrics
X9318WS8IZT1 absolute maximum ratings: (1)Junction Temperature under bias: -65 to +135℃; (2)Storage temperature: -65 to +150℃; (3)Voltage on CS, INC, U/D and VCC with respect to VSS: -1V to +7V; (4)RH, RW, RL to ground: +10V; (5)Lead temperature (soldering 10s): 300℃; (6)IW (10s): ±6mA.
Features
X9318WS8IZT1 features: (1)Solid-state potentiometer; (2)3-wire serial interface; (3)Terminal voltage, 0 to +8V; (4)100 wiper tap points; (5)99 resistive elements; (6)Low power CMOS; (7)High reliability; (8)RTOTAL value = 10kΩ; (9)Packages: 8 Ld SOIC and DIP; (10)Pb-free plus anneal available (RoHS compliant).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 X9318WS8IZT1 |
|
IC XDCP 100-TAP 10K 8-SOIC |
Data Sheet |
|
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
 |
X9311 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
X9312 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
X9313 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
X9313UM-3T1 |
|
IC XDCP 32-TAP 50K 3-WIRE 8-MSOP |
Data Sheet |
Negotiable |
|
||||||
|
X9313UM-3T2 |
|
IC XDCP 32-TAP 50K 3-WIRE 8-MSOP |
Data Sheet |
Negotiable |
|
||||||
|
X9313UMI |
|
IC DIGITAL POT 50K 32TP 8MSOP |
Data Sheet |
Negotiable |
|
||||||
