Product Summary

The IRFB3607PBF is a HEXFET Power MOSFET. It has some applications:(1)High Efficiency Synchronous Rectification in SMPS; (2)Uninterruptible Power Supply; (3)High Speed Power Switching; (4)Hard Switched and High Frequency Circuits.

Parametrics

IRFB3607PBF absolute maximum ratings: (1)ID @ TC = 25℃ Continuous Drain Current, VGS @ 10V: 80A; (2)D @ TC = 100℃ Continuous Drain Current, VGS @ 10V: 56A; (3)IDM Pulsed Drain Current: 310A; (4)PD @TC = 25℃ Maximum Power Dissipation: 140W; (5)VGS Gate-to-Source Voltage: ±20V; (6)dv/dt Peak Diode Recovery: 27V/ns; (7)TJ,TSTG: -55 to + 175℃.

Features

IRFB3607PBF features: (1)Improved Gate, Avalanche and Dynamic dv/dt Ruggedness; (2)Fully Characterized Capacitance and Avalanche SOA; (3)Enhanced body diode dV/dt and dI/dt Capability.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IRFB3607PBF
IRFB3607PBF

International Rectifier

MOSFET MOSFT 75V 80A 9.0mOhm 56nC Qg

Data Sheet

0-1: $1.24
1-25: $0.80
25-100: $0.58
100-250: $0.54
