Product Summary

The CP2102-GMR is a single-chip USB to uart bridge controller providing a simple solution for updating RS-232 designs to USB using a minimum of components and PCB space. The CP2102-GMR includes a USB 2.0 full-speed function controller, USB transceiver, oscillator, EEPROM, and asynchronous serial data bus (UART) with full modem control signals in a compact 5 × 5 mm QFN-28 package. No other external USB components are required. The on-chip EEPROM may be used to customize the USB Vendor ID, Product ID, Product Description String, Power Descriptor, Device Release Number, and Device Serial Number as desired for OEM applications.

Parametrics

CP2102-GMR absolute maximum ratings: (1)Ambient temperature under bias: min=-55℃, max=125℃; (2)Storage Temperature: min=-65℃, max=150℃; (3)Voltage on any I/O Pin or RST with respect to GND: min=-0.3V, MAX=5.8V; (4)Voltage on VDD with respect to GND: min=-0.3V, max=4.2V; (5)Maximum Total current through VDD and GND: max=50mA; (6)Maximum output current sunk by RST or any I/O pin: max=100mA.

Features

CP2102-GMR features: (1)Integrated USB transceiver; no external resistors required; (2)Integrated clock; no external crystal required; (3)Integrated 1024-Byte EEPROM for vendor ID, product ID, serial number, power descriptor, release number, and product description strings; (4)On-chip power-on reset circuit; (5)On-chip voltage regulator: 3.3 V output; (6)100% pin and software compatible with CP2101.

Diagrams

CP2102-GMR system diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CP2102-GMR
CP2102-GMR

Silicon Labs

Peripheral Drivers & Components (PCIs) USB-TO-UART BRIDGE

Data Sheet

0-1: $1.65
1-25: $1.59
25-50: $1.56
50-100: $1.53
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CP2101
CP2101

Silicon Labs

Peripheral Drivers & Components (PCIs) Single Chip USB to UART Bridge

Data Sheet

Negotiable
CP2101-9R
CP2101-9R


EURO-CASSETTE 110W 2X 3.3V&5.1V

Data Sheet

0-5: $454.74
CP2101EK
CP2101EK

Silicon Labs

Development Boards & Kits - 8051 USE 634-CP2102EK FOR NEW DESIGNS

Data Sheet

Negotiable
CP2101-GM
CP2101-GM

Silicon Labs

Peripheral Drivers & Components (PCIs) USB TO UART BRIDGE

Data Sheet

0-1: $2.07
1-25: $1.99
25-100: $1.91
100-1000: $1.75
CP2101-GMR
CP2101-GMR

Silicon Labs

Peripheral Drivers & Components (PCIs) USB TO UART BRIDGE

Data Sheet

0-1500: $1.76
CP2101R
CP2101R

Silicon Labs

Peripheral Drivers & Components (PCIs) USB to UART Bridge

Data Sheet

Negotiable
