Product Summary

The 60CPQ150PBF is a center tap Schottky rectifier. It has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 175℃ junction temperature. Typical applications of the 60CPQ150PBF include in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.

Parametrics

60CPQ150PBF absolute maximum ratings: (1)IF(AV), Rectangular waveform: 60 A; (2)VRRM: 150 V; (3)IFSM @ tp = 5μs sine: 2300 A; (4)VF @ 30 Apk, TJ= 125℃ (per leg): 0.67 V; (5)TJ range: - 55 to 175℃.

Features

60CPQ150PBF features: (1)175℃ TJ operation; (2)Center tap TO-247 package; (3)High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance; (4)Low forward voltage drop; (5)High frequency operation; (6)Guard ring for enhanced ruggedness and long term reliability; (7)Lead-Free (PbF suffix).

Diagrams

60CPQ150PBF block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
60CPQ150PBF
60CPQ150PBF

DIODE SCHOTTKY 150V 30A TO247AC
Data Sheet
0-1: $3.23
1-10: $2.89
10-25: $2.60
25-100: $2.37
100-250: $2.14
250-500: $1.92
500-1000: $1.62
1000-2500: $1.54
2500-5000: $1.47
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
60CPF
60CPF
Other

Data Sheet
Negotiable
60CPF..
60CPF..
Other

Data Sheet
Negotiable
60CPF.. HV
60CPF.. HV
Other

Data Sheet
Negotiable
60CPF02
60CPF02
Vishay Semiconductors
Rectifiers 200 Volt 60 Amp
Data Sheet
Negotiable
60CPF02PBF
60CPF02PBF

DIODE FAST REC 200V 60A TO247AC
Data Sheet
Negotiable
60CPF04
60CPF04
Vishay Semiconductors
Rectifiers 400 Volt 60 Amp
Data Sheet
Negotiable
